CONFERENCE MICROPHONE← Back to Speaker Phones
M200
Cascading Omnidirectional Digital Array Microphone
The ATVI M200 is a cascading omnidirectional digital array microphone for business meetings and interactive teaching. Six high-SNR digital microphones in a ring give 360° pickup — 3m clear and 6m effective — and up to 6 units cascade over PoE. Built-in AI blind beamforming and AEC / ANS / AGC remove noise, echo and howling, with USB-C and AUX outputs.
6 MicsHigh-SNR ring array
360°Omnidirectional
6mEffective pickup
Up to 6PoE cascade
AI 3AAEC / ANS / AGC
USB + AUXOutputs
M200 Key Advantages
- 6 high-SNR digital microphones in a ring array
- 360° pickup — 3m clear, 6m effective range
- Cascade up to 6 units over PoE for any room size
- AI blind beamforming locates and follows the speaker
- AEC, ANS and AGC remove echo, noise and howling
- Built-in audio processor — no external DSP needed, ultra-low latency
- USB-C (UAC1.0) and AUX1 / AUX2 analog inputs and outputs
- Desktop, ceiling or hanging installation
- Works with Windows, macOS and Linux
Ideal For
Business Meetings
360° pickup for the full table
Interactive Teaching
PoE cascade for larger classrooms
Large Conference Rooms
Ceiling or desk mount
Remote Collaboration
AI noise suppression for clear calls
Technical Specifications
| Microphone | |
|---|---|
| Microphone Array | 6 high-SNR digital microphones |
| SNR | 65 dB(A) |
| Sensitivity | -38 dBFS |
| Sampling Rate | 32K |
| Pickup | Omnidirectional, 360° |
| Pickup Distance | 3m clear, 6m effective |
| Cascades | Up to 6 |
| Audio & Interfaces | |
| Audio Algorithm | AEC, ANS, AGC |
| USB | USB audio (Type-C), UAC1.0, firmware upgrade and settings |
| Analog Audio | AUX1, AUX2 inputs and outputs |
| Network | RJ45 uplink and downlink cascade ports |
| Cascade Method | PoE |
| Control | Mute button |
| General | |
| Power | PoE 48V (IEEE 802.3at) or USB 5V 500mA (single unit) |
| OS Support | Windows, macOS, Linux |
| Certification | CE, RoHS, FCC |
| Dimensions | Φ170 × H40 mm |
| Weight | 370g |
Interested in the M200?
Get a quote or book a free live demo with our team.
Specifications and features are subject to change. Refer to the downloadable datasheet for the latest information.
