1/2.8 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 60fps.
Just plug in your device on CPU and it is ready to use. No waste of time installing driver etc
| Model | AT2100 -05X | AT2100V -10X | AT2100V1 -12X | AT2100V2-20X | AT2100V3-30X |
|---|---|---|---|---|---|
|
Camera Parameter |
|||||
|
Optical Zoom |
5X f＝3.6～15.5mm |
10X f＝4.7～47mm |
12X f＝3.9～46.8mm |
20X f＝5.2～110mm |
30X f＝4.3～129mm |
|
Sensor |
1/2.8 inch high quality HD CMOS sensor |
||||
|
Effective Pixels |
16: 9, 2.07 megapixel |
||||
|
Video Format |
SDI video format 1080P60/50/30/25/59.94/29.97; 1080I60/50/59.94; 720P60/50/30/25/59.94/29.97 |
||||
|
View Angle |
20°(tele) 83.7°(wide) |
6.43°(tele) 60.9°(wide) |
6.3°(tele) 72.5°(wide) |
3.3°(tele) 54.7°(wide) |
2.34°(tele) 65.1°(wide) |
|
AV |
F1.6 – F3.0 |
F1.6 – F3.0 |
F1.8 – F2.4 |
F1.6 – F3.5 |
F1.6– F4.7 |
|
Digital Zoom |
10x |
||||
|
Minimum Illumination |
0.1Lux |
||||
|
DNR |
2D & 3D DNR |
||||
|
White Balance |
Auto / Manual/ One Push/ 3000K/ 4000K/5000K/6500K |
||||
|
Focus / Aperture / Electronic Shutter |
Auto/Manual
|
||||
|
BLC |
ON/OFF |
||||
|
WDR |
OFF/ Dynamic level adjustment |
||||
|
Video Adjustment |
Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve |
||||
|
SNR |
>55dB |
||||
| Topic | Details |
|---|---|
|
Video Interfaces |
USB, LAN, HDMI ,RS232, Audio-In |
|
Video Compression format |
H.264, H.265, Dual stream output |
|
Audio Input Interface |
Double track 3.5mm linear input |
|
Audio Compression format |
AAC/MP3 Audio compression |
|
LAN Port |
Support VISCA protocol control through IP Port |
|
Network Protocol |
RTSP,TRMP, ONVIF, GB/T28181 |
| Topic | Details |
|---|---|
|
Control Protocol |
VISCA / Pelco-D / Pelco-P; Baud Rate : 115200 / 9600 / 4800 / 2400bps |
|
Audio Input Interface |
Double track 3.5mm linear input |
|
Audio Compression Format |
AAC / MP3 / PCM Audio compression |
|
HD IP Interface |
100M IP Port (100BASE-TX); Support VISCA protocol control through IP port |
|
Network Protocol |
RTSP, RTMP, ONVIF, GB/T28181, NDI |
|
Power Interface |
HEC3800 Outlet (DC12V) |
| Topic | Details |
|---|---|
|
Pan/Tilt Rotation |
+-170 degree, -30 degree–+90 degree |
|
Pan Control Speed |
0.1—60 degree/sec |
|
Present Speed |
Pan:60 degree/sec, Tilt 30 degree/sec |
|
Dimension |
150mmX150mmX167.5mm |
|
Weight |
1.4Kg |
|
Remote Operation (IP) |
Remote Upgrade, Reboot and Reset |
